SRACER 207 FPV RACING QUAD
- Unique frame design manufactured with high quality materials
- Extremely strong
- Light weight, under 300 gr. ready to fly!
- CNC aluminum camera mounting system with broad adjustment range and super durability
- Dedicated video transmitter mounting location
- CNC aluminum XT60 mounting bracket for clutter free battery wiring
- Dedicated zip tie slots for easier mounting of electronics
- Includes additional set of spacers for increased clearance
Empfohlene RC Austattung:
- 4 x Propeller (5 inch, pitch 4.5)
2-Blatt (Sportklasse, Einsteiger) z.B. DAL 5045
3-Blatt (mehr Power & Möglichkeiten) z.B. DAL T5045
- 4 x Motor - 2204 / 2206er Größe, 2000-2700kv
z.B. - XNOVA 2204-2600 Racing Combo, XNOVA 2206-2500 Racing Combo
- 4 x Brushless Regler / ESC 20-35A, 3-4S Lipo Cells
- Camera HS1177 Größe oder ähnliche
- Videosender & Antenne
FX799 oder ähnliche
- 6 Kanal Empfänger
- Flight Controller Board
Naze32, Lux, DoDo, SP F3 ...
- Lipo Akku 3S oder 4S, 1300-1800mAh, min. 35C, XT60 Stecker empfohlen
Einsteiger: 3S 1300-2300mAh
Power User: 4S 1300-1600mAh
The most versatile frame on the market today!
üThe sRacer 207 is the result of a collaboration between RC industry leading engineers and marketers that were looking to develop a versatile quad that could satisfy the most discerning FPV pilot by incorporating features never seen before in a simple “X” style frame.
The sRacer is extremely light weight and easy to build. Features such as a fully adjustable CNC aluminum camera mount, dedicated VTX mounting location and CNC aluminum XT60 connector bracket among others are sure to please beginners as well as expert racers alike. The camera mount is fully adjustable- from straight and level to over 70 degrees of upwards tilt!
Do you prefer freestyle? Not to worry! The sRacer’s optional CNC aluminum GoPro camera mount is strong, light weight and fully adjustable allowing you to match the angle of your FPV camera for best video recording.
Want a competitive edge at the races? When used with the sLauncher, the sRacer is sure to give you that advantage you need at the beginning of the race allowing you to see your initial gate before launch and get the head start on the competition.
